Single Tunnel Plastic Film Greenhouse

Spring Agri Equipment is a proficient manufacturer and supplier of Single Tunnel Plastic Film Greenhouse in China. The structure of Tunnel greenhouse is a circular arch that looks like a tunnel from the inside, and is usually a single arch for a building unit. The main covering is film, which can be configured with different materials, different lighting rates and different colors according to planting crops and use requirements. TOP greenhouse can manufacture various single tunnel plastic film greenhouses for different requirement.

One of Chinese manufacturer of Single Tunnel Plastic Film Greenhouse, offering excellent quality at a competitive price, is Spring Agri Equipment. The span is 6-14 meters. The frame is all hot-dip galvanized square pipe or round pipe, and both sides of the greenhouse are provided with manual film rollers and insect-proof nets. It is generally built from south to north, and all materials of the tunnel greenhouse are produced in China, assembled and inserted, and can be disassembled and reused.

The Advantages Of Tunnel Plastic Film Greenhouse

1、 Small investment and low construction cost

2、 Simple structure, convenient construction and disassembly, can be used repeatedly

3、 Planting vegetables and flowers has little risk and is suitable for farmers to plant large areas

4、 Simple management, less labor

5、 Environmental control and temperature control are easy to operate

In order to meet the needs of use of plastic film greenhouse, the top can fix ventilation window, the side roll film ventilation window, set electric ventilation fan on the gables, configure the wet curtain, the manual sunshade.



Parameters And Specifications

Dimension Parameter

Load Parameter

SpanLength

6、8、9、9.6、11.2、12.8m

Wind Load

40~120km/h

Bay Length

0.5~2.0 m

Snow Load

0~100cm

Top Height

3.5~6.0m

Hanging Load

0~15Kg/M²

Shoulder Height

1.5~3.0 m

Maximum Drainage Capacity

Skeleton Frame

Covering Materials

Hot Dip Galvanized Steel Tubes

☑PO Film、☑PEP Film、□Glass、☑PCSheet

Optional Systems

Ventilation system, circulating system, shading system, planting system, irrigation system, water and fertilizer integration, electrical control system

Applications

Leafy Vegetables, Eggplants, Mushrooms, Flowers, Seedlings, Poultry, Fish Pond Shed, Parking Shed, Material Warehouse

Marks

The above parameters just for reference and subject to our actual projects, we accept customization

Feature And Application

It is suitable for home gardens, spring and autumn vegetables, flower farming, the obvious advantage is to save cost and widely planting. Our factory has provided lots of cheap and most economical tunnel plastic film greenhouses, in the countryside, this kind of greenhouses can be seen everywhere, and farmers have become very skilled in using it to grow strawberries, tomatoes, watermelon, cabbage.
